Food and Beverage
Seals and gaskets for food and beverage lines
The compliance line belongs to the compound, never to the material family and never to the color, so a white seal proves nothing on its own. Conquest Seal supplies O-rings and waterjet-cut gaskets on compounds that carry the listing your line actually needs, and the paperwork that shows it. If your plant, your auditor or your customer names a standard, send it with the part and we quote to it. Send the part number or the drawing, the quantity and the listing required, and a Conquest representative replies with the quote.
Photo by Sean Foster.
- Standards
- NSF/ANSI 51, NSF/ANSI 61, KTW, WRAS on named compounds; ASTM D2000 callouts on sheet
- Typical seals
- O-rings, waterjet-cut sanitary flange and lid gaskets, custom molded parts to print
- Materials
- Peroxide-cured EPDM (-57 C to 150 C continuous; Parker® E3609-70 sheet, read 2026-08-13), silicone, FKM, PTFE sheet
- Quality
- Certificate of conformance naming the part number, the specification, the manufacturer, the lot and the quantity, with the compound listing documentation.
Two things decide a food or beverage seal: what it touches, and what it has to be cleaned with. Clean-in-place chemistry is often harder on a compound than the product ever is.
Materials by duty
Hot water, steam and caustic cleaning point one way; fats, oils and flavor oils point the opposite way, and no single compound is good at both. Where a line runs both, the answer is usually two different seals rather than one compromise. The material by temperature and media guide walks through it.
Reading the compliance line
A listing is granted to a named compound, tested as that compound. A drawing that says only food grade EPDM has not specified anything a supplier can quote against, so tell us the standard the plant is audited to and we quote the listed compounds the makers offer against it.
Gaskets
Flat gaskets are cut to your drawing on our own waterjet from a DXF, with no tooling, which suits the one-off shapes a plant ends up needing. See gaskets.
What we supply
Product lines for food and beverage
O-rings
The part most people mean by a seal. We stock every AS568 size.
Gaskets
Seals the joint between two flat faces, cut to your drawing on our own waterjet in Orange, California, with no tooling.
Custom molded rubber
Parts no catalog carries, made to your drawing by the molders we source from, by compression, transfer or injection molding.
Rubber compounds
For prints that name a compound rather than a part. Standard grades and the AMS and MIL specification grades a drawing can call out.
Materials
What comes up on food and beverage prints
- EPDM O-Rings
- Hot water, steam and clean-in-place chemistry. Never fats or oils.
- Silicone O-Rings
- Wide temperature swings, with listed grades available.
- Viton® (FKM) O-Rings
- Fats, oils and flavor oils that would swell other compounds.
- Buna-N O-Rings
- General service on the utility side of the line.
The compound named on your print governs. Send it with the part number and we quote that compound.
Viton is a trademark of The Chemours Company. Parker is a trademark of Parker Hannifin Corporation. No affiliation or endorsement is implied.
Related guides
What to send us
The part number or the drawing, the quantity, the listing the line needs and the compound your print names.
